FOIL Bar

The foil bar is available in 50 & 60 cm and equipped with 13 / 14 / 15 / 17 & 19 m long stiff lines.

  • Available in 2 sizes : 50 & 60 cm
  • One line flag out system
  • Manual swivel to untwist your front lines
  • Only one bar for HALO or any DIABLO kite
Read more...

Technical Specifications

Slim & lightweight, the clean design of the bar allows a comfortable and controlled ride.

In order to reduce drag and increase performance, the floats are removable.

The 60 cm depower is made with a high density polyethylene sheath to reduce wear when sheeting in and out. The hoist made of a fixed F-ONE pulley and a RONSTAN® pulley with ball bearing system allows a precise trimming with no efforts.

The leader lines are adjustable from the knot scale inside the floats. The FOIL BAR offers reliable safety functions such as the manual swivel on top of the quick as well as the release set up on a single line.

The FOIL BAR is delivered with a short 40 cm safety leash.

AFNOR: NF S52-503

LINES TYPE DIAM (mm) STIFFNESS LENGTH (m)
STANDARD 1.5 ++ 13 14 14 17* 19*
STANDARD 1.5 + 14 15 17
COMPETITION 1 +++ 13 14 15 17

*Recommended for HALO

SIZE RECOMMENDATION – DIABLO & HALO
KITE SIZE (m2) 8 10 12 15 19
FOIL BAR (cm) <50> <60>
MONOLITH BAR (cm) <48> <55> <65>
  • FOIL BAR

3D view
