SEVEN SEAS CARBON

The SEVEN SEAS is the foil that will help you ease into the amazing downwind world and provide incredible glide sensations.

  • Aspect Ratio: 7.5
  • Fantastic glide, upwind, and speed abilities
  • Makes downwind foiling accessible
  • Thin profile and optimized design for minimal drag



Available in 1000 cm²/1200 cm² / 1400 cm²
Ref.  77227-0141 / 77227-0142 / 77227-0143

Read more...
SEVEN SEAS CARBON 6
Plane
SEVEN SEAS CARBON 7
1000
SEVEN SEAS CARBON 8
1200
SEVEN SEAS CARBON 9
1400

Product video

Program

90%
Speed
85%
Carving
90%
Pumping
90%
Glide

Technical Specifications

The SEVEN SEAS’s high aspect ratio and thin profile brings great downwind abilities and offers the best glide. The front wing is equipped with fences on the wingtips to reduce the induced drag and improve the foil’s overall performances and maneuverability.

Once you’re up to your cruising speed, its lift will make it easy for you to keep your glide for a long time. Pumping is reliable and constant even at low speeds, and you will be able to connect the waves and catch any upcoming bumps more easily. This new line positions itself perfectly as an intermediary between the EAGLE HM CARBON and the PHANTOM CARBON ranges.

Built using the Monobloc structure with pre-preg carbon, the foils are both very light and strong. This setup brings improved load transmission and better stiffness throughout the different parts for maximum control. The TITAN connection allows to plug in either an aluminum or carbon mast, and the fuselage is split in two to facilitate transport.

The SEVEN SEAS foils are available in 1000 cm², 1200 cm², and 1400 cm². They are recommended with the new C250 FENCE stab. This stabilizer is also set up with fences to bring even more maneuverability to the entire plane.

If you already ride with a PHANTOM foil and wish to improve your glide in downwind, the SEVEN SEAS is made for you.

AREA (cm²) SPAN (cm) ASPECT RATIO WEIGHT (kg)
SEVEN SEAS 1000 1000 86.5 7.5 1.35
SEVEN SEAS 1200 1200 95 7.6 1.44
SEVEN SEAS 1400 1400 103.5 7.5 1.61



SEVEN SEAS CARBON 11

  • CARBON HYDROFOIL USER GUIDE

3D view
